20W Powerful Cutting
The 22-24W optical output laser modules largely boosts the cutting capacity of the Ray5. It cuts through 25mm wood and 35mm acrylic by multiple passes, and cut 0.002"/0.05mm stainless steel.
Higher Accuracy Cutting & 0.08*0.1mm² High Accuracy Laser Spot
The Ray5 is equipped with an ultra-fine 0.08 x 0.1mm focus point, producing thinner lines, clearer texture, and more precise artwork .


More Productivity
More power leads to faster engraving and cutting, and a wider variety of materials that you can use. Ideal for professional work, workshops, or factories .
Multi-Color Engraving
The 22-24W laser instantly oxidizes metal, bringing vibrant colors to fulfill your creative needs.


X/Y-axis Limit Switches
Limit switches can accurately locate the position of the laser module, allowing for a safety feature where the Ray5 will trigger an alarm if it detects the laser is moving in the wrong direction.
Safety Measures
Installed Move/Thermal/Offline/Motionless/Eye Protections.


Laser Lens Protection
The 22-24W model is equipped with a replaceable lens and dust-proof hood which prevents smoke from polluting the lens.

Data Transfer Methods
Supports Wi-Fi, USB, APP and TF cards. The Ray5 is not limited to a physical computer connection.

Multiple Machines Control
The Ray5 can work either with one terminal, or can be set to work parallel with other units to improve production efficiency.

Wide Compatibility
Compatible with LaserGRBL, LightBurn and supports Windows 7+, macOS, and Linux.Supported file formats: JPG, PNG, BMP, G- code, GIF, SVG, NC, GC, etc.

3.5” Touch Screen
Both the 5W and 10W models are equipped with a 3.5” touch screen which doesn’t require a wireless connection while engraving and cutting.

Adjustable Focus Plate
The focus plate is easy to adjust, and is equipped with a 1mm pitch scale to precisely adjust the focal length according to the thickness of the material.

32-Bit Chipset
The Ray5 is equipped with a ESP32 chipset, running at 240M Hz, allowing it to run faster and more powerfully compared to machines with a generic 8-bit chipset.
Model Number | Ray5 20W | Ray5 10W | Ray5 5W |
---|---|---|---|
Laser Technology | Dioser Technology | Dioser Technology | Dioser Technology |
Working Area | 375x375 mm (14.76x14.76 inch) | 400x400mm (15.75x15.75inch) | 400x400mm (15.75x15.75inch) |
Laser Wavelength | 450 - 460 nm | 450nm | 450nm |
Focal Length | Fixed Focus-40mm | Fixed Focus-50mm | Fixed Focus-30mm |
Laser Spot Size | 0.08x0.10mm | 0.06x0.06mm | 0.08x0.08mm |
Optical Output Power | 18 - 21 W | 10W | 5W |
Power Max Consumption | 120W | 60W | 40W |
Engraver Output | DC24V 5A | DC12V 5A | DC12V 5A |
Engraver Input | AC110-240V | AC110-240V | AC110-240V |
Z Axis-Height Range | Up to 47mm | Up to 47mm | Up to 47mm |
Fastest Working Speed | Speed 10000mm/min | Speed 10000mm/min | Speed 10000mm/min |
Software | LaserGRBL & LightBurn | LaserGRBL & LightBurn | LaserGRBL & LightBurn |
Input Image Format | JPG, PNG, BMP, GIF, SVG, AI, etc. | JPG, PNG, BMP, GIF, SVG, AI, etc. | JPG, PNG, BMP, GIF, SVG, AI, etc. |
Connection type | USB / TF Card / Wifi | USB / TF Card / Wifi | USB / TF Card / Wifi |
limit switches | Yes | Optional | Optional |
Air assist interface | Yes | Optional | Optional |
Laser Engraver Size | 610 x 67 x 200 mm (24.02 x 26.38 x 7.87 inch) | 586 x 583 x 176.5mm (23.07x22.95x6.95inch) | 586 x 583 x 176.5mm (23.07x22.95x6.95inch) |
Packaging Size | 621 x 347 x 127mm (24.45 x 13.66 x 5 inch) | 621x299 x 127mm (24.45 x11.77 x 5 inch) | 621 x 299 x 127mm (24.45 x 11.77 x 5 inch) |
