Triangle Design
A dual-rod, steady system enhancing printing precision.

Quiet Printing
Three TMC2208 chipsets ensuring minimal nosise.

4.3" Touch Screen
Built-in 4.3” touchscreen improving UI experience.

Easy Removal of prints
Ceramic-coated glass for easy removal of prints.

Resistance to High Temperatures
Use of teflon tubes minimizing clogging.

Pre-assembled
90% assembled for easy installation.
MODEL | LK5 PRO |
---|---|
Printing Technology | FDM 3D Printing Technology |
Printed Size | 300*300*400mm (11.8"*11.8"*15.7") |
Printing Temperature | 190-250℃ |
Nozzle Diameter | 0.4mm |
Filament Detector | Yes |
Resume Printing | Yes |
Printing Speed | ≦180mm/s (Suggest 60-80mm/s) |
Slice Software | Cura, Reptier-Host |
Connection | TF Card or USB Cable |
Gross Weight | 13.5KG |
Printer Dimension | 580*540*663mm |
Package Dimension | 662*588*193mm |


Triangle Design
Our new dual inclined rod system holds the Z-axis steady during use in order to increase precision.

Quiet Printing
This model is equipped with three TMC2208 chipsets, which drives the X/Y/Z axes, and ensures minimal noise while printing.

Touchscreen
This model comes with a built-in 4.3” touchscreen with a new and improved UI for a more user-friendly approach.

Easy Removal
The LK5 PRO comes with ceramic-coated glass, which provides better adhesion for easy removal of your prints and a more level surface for the printing bed.

Resistance to High Temperatures
The use of teflon tubes gives the printer resistance to higher temperatures, reducing the possibility of clogging after repeated use.

Pre-assembled
The printer ships to you 90% assembled, requiring very minimal construction efforts.
Parts List in Package

Manual x 1

Card Reard x 1

TF Card x 1

Scraper x 1

Tool Set x 1

Power Cord x 1

Test PLA x 1

Filament Sensor x 1

Screws Set x 1
3D printer project by LK5 Pro
Download

Catalog
LK5 PRO

Manual
Detail Manual

Firmware
FW&UI_LK5_PRO_0_3_5C

Slice Software
Longer Cura 1.3
Latest Cura

TF Card
Content Download

Tools
Format TF Card Tool
