Longer RAY5 10W (10-12W Output Power)

Regular price $529.99 Sale price$339.99
/

  • 10-12W Output Power, Strong Cutting Capability
  • Ultrafine 0.06*0.06mm Laser Focus Point
  • High Accuracy Laser Engraving¬†& Cutting
  • Large¬†Working¬†Space: 400mm*400mm(15.75''*15.75'')
  • 3.5''¬†Built-in¬†Touch¬†Screen¬†&¬†Offline¬†Work
  • Engrave¬†up¬†to¬†1000+¬†Materials:¬†Wood,¬†Metal,¬†Acrylic,¬†Glass,¬†Leather,¬†etc.
  • Upgradable to 20W¬†Laser¬†Engraver Module
  1. Free shipping in the US/EU, shipped in 3 business days
  2. PS: Non-US and non-EU regions may incur additional customs duties when shipping, such as the UK and Switzerland
  3. Orders may be seperated to ship, learn more about Shipping.
Ship to

Best Performance and Most Cost-efficient: Powerful, Precise and Safe!

Ray5 10w with 3.5" touch screen added new functionality like multiple ways for data transfer and multiple machines control. Compared to other laser engravers, it can engrave up to 1000+ materials.

10W Compressed Spot Cuts up to 20mm Wood or 30mm Acrylic

Boasting dual beam laser technology, the Ray5 10W Engraver has more cutting power and a greater engraving capacity. 400 x 400mm engraving size Maximum engraving speed of 10,000 mm/min.

Higher Accuracy Cutting & Engraving 0.06 x 0.06mm Laser Spot

The Ray5 boasts the latest compressed laser technology, generating an ultra-fine laser which is up to 2x thinner than generic lasers, making engraving more precise, consistent, and clearer.

Flame Protection & Alarm

The Ray5 is equipped with a thermal sensor, which will stop the laser and generate an alarm when an accidental flame is detected. Furthermore, the protective cover now boasts fireproof acrylic which improves the printer’s resistance to flame.

High Accuracy Cutting &  Engraving
0.06*0.06mm2 Laser Spot

Ray5 adopts the latest compressed laser technology, which generates an ultra-fine laser spot, two times thinner than ordinary lasers, making Ray5's cutting & engraving work more precise and consistent, with thinner lines, clearer texture, and more delicate and beautiful artwork.

3.5‚ÄĚ Touch Screen

Both the 5W and 10W models are equipped with a 3.5‚ÄĚ touchscreen which doesn‚Äôt require a wireless connection while engraving and cutting.

High Accuracy Cutting &  Engraving
0.06*0.06mm2 Laser Spot

Ray5 adopts the latest compressed laser technology, which generates an ultra-fine laser spot, two times thinner than ordinary lasers, making Ray5's cutting & engraving work more precise and consistent, with thinner lines, clearer texture, and more delicate and beautiful artwork.

Data Transfer

Supports Wi-Fi, USB, APP and TF cards. The Ray5 is not limited to a physical computer connection.

Multiple Machines Control

The Ray5 can work either with one terminal, or can be set to work parallel with other units to improve production efficiency.

Move Protection

There is a G-sensor on the motherboard. When the engraving machine is being accidentally displaced or tilted, it will automatically shutdown for personal safety.

Wide Variety of Uses

The Ray5 10W model can cut or engrave more than 1000 different materials, including wood, stainless steel, leather, most metals, acrylic, cloth, and more.

Flame Protection & Alarm

Equipped with a thermal sensor, when Ray5 detects any accidental flame while working, it will automatically stop the laser and generate a continuous buzz alarm. Also, the laser protective cover adopts newly fireproof acrylic with better flame resistance.

Stable Engraving

Engraves smoothly even while running at max speed.

Software Compatibility

Compatible with LaserGRBL, LightBurn and supports Windows 7, macOS, and Linux.
Supported file formats: JPG, PNG, BMP, G- code, GIF, SVG, NC, GC, etc.

Optimized Focus for Cutting

The Ray5 is equipped with an optimized focal design, improving its cutting ability and strength.

32-Bit Chipset

The Ray5 is equipped with a ESP32 chipset, running at 240M Hz, allowing it to run faster and more powerfully compared to machines with a generic 8-bit chipset.

Move Protection

The Ray5 is equipped with a G-sensor, which automatically shuts down the engraver when it senses that the machine is being tilted or moved.

Motionless Protection

The laser will automatically turn off if the module is frozen for over 15 seconds.

Model Number Ray5 5W Ray5 10W
Laser Technology Dioser Technology Dioser Technology
Working Area 400x400mm (15.75x15.75 inch) 400x400mm (15.75x15.75 inch)
Laser Wavelength 450nm 450nm
Focal Length Fixed Focus-30mm Fixed Focus-50mm
Laser Spot Size 0.08x0.08mm 0.06x0.06mm
Optical Output Power 5W 10W
Z Axis-Height Range Up to 47mm Up to 47mm
Fastest Working Speed Speed 10000mm/min Speed 10000mm/min
Engraver Output DC12V / 5A DC12V / 5A
Engraver Input AC110-240V AC 110-240V
Software LaserGRBL & LightBurnLaserGRBL & LightBurn
Connection USB / TF Card / Wifi USB / TF Card / Wifi
Laser Engraver Size 586 x 583 x 176.5mm (23.07x22.95x6.95 inch) 586 x 583 x 176.5mm (23.07x22.95x6.95 inch)
Package Size 621 x 299 x 127mm 621x299 x 127mm
