Incisore laser Ray5 20W

$859.99

$1,199.99

Taglio potente da 20 w,Laser a diodi quad-core,Taglia il legno di pino da 0,59 "/15 mm e acrilico 0,31"/8 mm in un passaggio （in legno da 25 mm e pass multipli acrilici da 35 mm）, anche 0,002 "/0,05 mm in acciaio inossidabile inossidabile

0,08*0,1 mm² Accuratezza ad alta precisione Incisione laser fai -da -te e taglio

Incisione multicolore sulla superficie del metallo, respira più vita nelle tue creazioni

Interruttore limite dell'asse XY e 5 protezioni di sicurezza, più sicure da utilizzare

Touch screen incorporato da 3,5 '' lavoro offline e supporto WiFi, app, cavo USB e TF Trasmissione dei dati delle schede TF

Dotato di obiettivo di protezione laser, cofano a prova di polvere e interfaccia di assistenza all'aria...

Disponibilità: 7 In magazzino

20W

NOI

Altra regione

20W Powerful Cutting

Ray5 20W has a 20W optical output powerful laser module, which comes with the most advanced laser enhancement technology and enhance the cutting capacity of this machine. It can cut 0.59"/15mm pine wood and 0.31"/8mm acrylic in one pass, 25mm wood and 35mm acrylic multiple passes, and cut 0.002"/0.05mm stainless steel.

0.08*0.1mm² High Accuracy Laser Spot

With the latest compressed laser technology, the laser spot is as tiny as 0.08*0.1mm², thus engraving thinner lines, clearer texture, more delicate and beautiful artworks. And air-assisted interface is reserved, which can be easily matched with various air pumps, more clean surfaces.

Work at Higher Efficiency

Ray5 20W is euipped with a 20W powerful laser output power and 120W electric power, deeper cutting at one time, smoother engraving with high power at high speed, and wider cutting and engraving materials, saving time. Suitable for professional office, workshops or factories.

Multi-Color Engraving

The 20W high-energy laser beam instantly oxidizes the metal surface, bringing rich colors to fulfill your colorful creative needs.

XY-axis Limit Switch

Added X-axis and Y-axis direction limit switches, which can accurately locate the position of the laser module. At the same time, if the laser module moves in the negative direction of the X-axis or Y-axis, Ray5 20W will trigger an alarm and restrict the movement.

5 Safety Protections

Laser emergency stop will be triggered when tilted, flame, data connection interruption and laser head freezing over 15 seconds are detected. In addition, the panoramic filter glassv can effectively filter the laser and protect the eyes, safer to use.

New Laser Lens Protection

The 20W laser module is euipped with a replaceable protective lens and dust-proof hood to effectively prevent smoke from polluting the laser lens, and greatly improve the service life of the laser module.

Multiple Transfer Ways

Data can be transferred via different methods of Wi-Fi, USB cable, APP and TF cards , which supports offline operations. You can use Ray5 anywhere, without the limits of physical connection to a computer.

Multiple Machines Control

One computer can control multiple Ray5 laser engravers work parallelly, Whether it is Ray5 5W, Ray5 10W or Ray5 20W, and improve the production efficiency.

Wide Compatibility

Ray5 20W is compatible with various mature carving software, such as LaserGRBL, LightBurn, supports Windows 7+, macOS, Linux; carving file formats Support JPG, PNG, BMP, G- code, GIF, SVG, NC, GC, etc.

3.5" Touch Screen

3.5-inch smart built-in color screen, it does not need to connect the laser engraving equipment to the computer, supports offline operations.

Adjust Focus Easily

The focus plate is easy to focuse. And there is a 1mm pitch scale on the laser module, which can precisely adjust the focal length according to the thickness of the material for engraving and cutting.

32-Bit Chipset

Ray5 20W is built with an ESP32 chipset, which is running at 240MHz. Faster and more powerful than comparably equipped machines with 8-bit chipset.

Model Number	Ray5 20W	Ray5 10W	Ray5 5W
Laser Technology	Dioser Technology	Dioser Technology	Dioser Technology
Working Area	375x375 mm (14.76x14.76 inch)	400x400mm (15.75x15.75inch)	400x400mm (15.75x15.75inch)
Laser Wavelength	450 - 460 nm	450nm	450nm
Focal Length	Fixed Focus-40mm	Fixed Focus-50mm	Fixed Focus-30mm
Laser Spot Size	0.08x0.10mm	0.06x0.06mm	0.08x0.08mm
Optical Output Power	18 - 21 W	10W	5W
Power Max Consumption	120W	60W	40W
Engraver Output	DC24V5A	DC12V5A	DC12V5A
Engraver Lnput	AC110-240V	AC110-240V	AC110-240V
Z Axis-Height Range	Up to 47mm	Up to 47mm	Up to 47mm
Fastest Working Speed	Speed 10000mm/min	Speed 10000mm/min	Speed 10000mm/min
Software	LaserGRBL&LightBum	LaserGRBL&LightBum	LaserGRBL&LightBum
Input Image Format	JPG, PNG, BMP, GIF, SVG, AI, etc.	JPG, PNG, BMP, GIF, SVG, AI, etc.	JPG, PNG, BMP, GIF, SVG, AI, etc.
Connection type	USB/TF Card/Wifi	USB/TF Card/Wifi	USB/TF Card/Wifi
limit switches	Yes	Optional	Optional
Air assist interface	Yes	Optional	Optional
Laser Engraver Size	610 x 67 x 200 mm (24.02 x 26.38 x 7.87 inch)	586 x 583 x 176.5mm (23.07x22.95x6.95inch)	586 x 583 x 176.5mm (23.07x22.95x6.95inch)
Packaging Size	621 x 347 x 127mm (24.45 x 13.66 x 5 inch)	621x299 x 127mm (24.45 x11.77 x 5 inch)	621 x 299 x 127mm (24.45 x 11.77 x 5 inch)
