Regular price $799.00 Sale price$559.99
/

  • Quad-Core Diode Laser, 22-24W Output, Powerful Cutting Capability
  • Ultra-fine 0.08 x 0.1mm focus point
  • Multi-color engraving on metal surfaces
  • Comes with Air Assist Nozzles (Pump not included) and a laser protection lens.
  • X/Y-axis limit switches, as well as 5 safety measures
  • 3.5” Touch Screen, which supports WiFi, APP, USB, and TF cards
Ship to
Bundle Item
paypal visa master maestro jcb american express diners club discover klarna
  1. Free shipping in the US/EU, shipped in 3 business days
  2. PS: Non-US and non-EU regions may incur additional customs duties when shipping, such as the UK and Switzerland
  3. Orders may be separated to ship, learn more about Shipping.
A+-1.jpg__PID:6eb6edb7-45aa-44b0-b18b-1fede8dbc185A+-2.jpg__PID:b6edb745-aa44-4031-8b1f-ede8dbc185f2A+-3.jpg__PID:edb745aa-44b0-418b-9fed-e8dbc185f2abA+-4.jpg__PID:b745aa44-b031-4b1f-ade8-dbc185f2ab94A+-5.jpg__PID:45aa44b0-318b-4fed-a8db-c185f2ab948cA+-6.jpg__PID:aa44b031-8b1f-4de8-9bc1-85f2ab948c4fA+-7.jpg__PID:44b0318b-1fed-48db-8185-f2ab948c4ff6A+-8.jpg__PID:b0318b1f-ede8-4bc1-85f2-ab948c4ff612A+-9.jpg__PID:318b1fed-e8db-4185-b2ab-948c4ff612afA+-10.jpg__PID:8b1fede8-dbc1-45f2-ab94-8c4ff612afbdA+-10.jpg__PID:8b1fede8-dbc1-45f2-ab94-8c4ff612afbdA+-14.jpg__PID:61bd7dee-7b76-4341-b82f-b5add8b68999A+-14.jpg__PID:61bd7dee-7b76-4341-b82f-b5add8b68999A+-11.jpg__PID:85f2ab94-8c4f-4612-afbd-a56a788c710fA+-12.jpg__PID:f2ab948c-4ff6-42af-bda5-6a788c710f6fRay5-20w-首图1.jpg__PID:bf2e2f1b-ce9c-4040-abe7-246bbe02638c
 20W Powerful Cutting

20W Powerful Cutting

The 22-24W optical output laser modules largely boosts the cutting capacity of the Ray5. It cuts through 25mm wood and 35mm acrylic by multiple passes, and cut 0.002"/0.05mm stainless steel.

Higher Accuracy Cutting & 0.08*0.1mm² High Accuracy Laser Spot

The Ray5 is equipped with an ultra-fine 0.08 x 0.1mm focus point, producing thinner lines, clearer texture, and more precise artwork .

 Higher Accuracy Cutting & 0.08*0.1mm² High Accuracy Laser Spot
Faster engraving and cutting

More Productivity

More power leads to faster engraving and cutting, and a wider variety of materials that you can use. Ideal for professional work, workshops, or factories .

Multi-Color Engraving

The 22-24W laser instantly oxidizes metal, bringing vibrant colors to fulfill your creative needs.

Multi Color Engraving
 X/Y-axis Limit Switches

X/Y-axis Limit Switches

Limit switches can accurately locate the position of the laser module, allowing for a safety feature where the Ray5 will trigger an alarm if it detects the laser is moving in the wrong direction.

Safety Measures

Installed Move/Thermal/Offline/Motionless/Eye Protections.

safety measures
laser lens protection

Laser Lens Protection

The 22-24W model is equipped with a replaceable lens and dust-proof hood which prevents smoke from polluting the lens.

data transfer methods

Data Transfer Methods

Supports Wi-Fi, USB, APP and TF cards. The Ray5 is not limited to a physical computer connection.

 Multiple Machines Control

Multiple Machines Control

The Ray5 can work either with one terminal, or can be set to work parallel with other units to improve production efficiency.

 Compatible with LaserGRBL, LightBurn

Wide  Compatibility

Compatible with LaserGRBL, LightBurn and supports Windows 7+, macOS, and Linux.Supported file formats: JPG, PNG, BMP, G- code, GIF, SVG, NC, GC, etc.

 3.5” Touch Screen

3.5” Touch Screen

Both the 5W and 10W models are equipped with a 3.5” touch screen which doesn’t require a wireless connection while engraving and cutting.

 Adjustable Focus Plate

Adjustable Focus Plate

The focus plate is easy to adjust, and is equipped with a 1mm pitch scale to precisely adjust the focal length according to the thickness of the material.

 Ray5 32-Bit Chipset

32-Bit Chipset

The Ray5 is equipped with a ESP32 chipset, running at 240M Hz, allowing it to run faster and more powerfully compared to machines with a generic 8-bit chipset.
